Hitec D955TW Standard Digital Coreless Servo 66g 29kg/0.12s 4.8V – 7.4V

Description

FEATURES

• Programmable PWM digital amplifier
• 32-Bit MCU with 12-Bit ADC circuitry
• 4096 Resolution
• 1M cycle long life potentiometer
• Wide operating voltage (4.8 ~ 8.4 Volts DC)
• Dual ball bearing supported output shaft
• 25-Tooth output spline
• Coreless metal brush motors

DETAILS

The D955TW servo is powered by our 32-bit MCU (Microcontroller Unit) and 12-bit ADC (Analog to Digital Converter) industrial science and possess Smart Sense engineering with rapid, high resolution response. Their unprecedented programmability and wide-voltage capabilities deliver the most progressive, leading-edge performance for all your radio control needs. The reliably-strong titanium-geared D955TW replaces the well-known HS-7955TH. Advancing servo technology and providing superior engineering has always been Hitec’s mission and that continues today.

Programmable Functions:

• End Point Adjustments
• Direction
• Fail Safe
• Dead Band
• Speed (Slower)
• Soft Start Rate
• Overload Protection
• Date Save/Load
• Program Reset

The D955TW servo is versatile and suitable for a wide range of radio control applications, including:

• Aircraft: Provides a precise control for various control surfaces, enhancing flight performance.
• Surface Vehicles: Ideal for steering and throttle control in cars, trucks and crawlers. Offering responsive handling.
• Helicopters: Delivers accurate cyclic and tail control inputs, crucial for stable flight dynamics.
• Boats: Enhances maneuverability and throttle response, contributing to improved watercraft performance.
